Applicable Fiber

Single core quartz fiber

Fiber diameter

Cladding Diameter：400-1000μm，Coating Diameter：450μm～3mm

Cleave length

8～16mm

Fiberdisplay

X、Y Separately or X、Y simultaneously

Automatic discharge
calibration

Available

Electrode life

5000

Protection sleeve

20～60mm and other special protection sleeve

Splicing Program

6 preset ，74 user programble

Heating Program

2

Auto heat

Available

Data Storage

8000 groups data record,128 groups image record

Language

Chinese, English.

Operating Condition

Operating Altitude: 0~5000m above sea level, 0~95% relative humidity, -10~50°C, Max Wind 15m/s

Storage Condition

0~95% relative humidity, -40~80°C

Power supplyAC adapter

AC input voltage 85～260V，50/60Hz

Display

4.3-inch color high-resolution LCD screen

Size / weight

360（D）×270（W）×438（H）mm/12kg
